| Vehicle Dimensions | |
|---|---|
| Length | 1890 mm |
| Width | 730 mm |
| Height | 1030 mm |
| Wheelbase | 1355 mm |
| Weight |
116 KGs (per battery Capacity)
|
| Payload | 250 KGs |
| Max. Speed | <25 KMPH |
|
*Range (per Charge)
|
100 KM – 110 KM |
| – | – |
| – | – |
| Motor | |
|---|---|
| Type | BLDC Motor |
| Output | 240 W @ 60 V |
| No Load Revolution | 350 RPM |
| Low Voltage Protection | 51 V |
| Battery | |
|---|---|
| Type | Lithium Ferrous Phosphate |
| Charging In | 4:30 hours – 5 hours |
| Capacity | 48 Ah |
| Voltage | 60 V |
| Controller | |
|---|---|
| Power Rating | 240 Watts |
| Operating Voltage | 60 V |
| Suspension | |
|---|---|
| Front | Telescopic Fork |
| Rear | Hydraulic Shock Absorbers |
| Tyre | |
|---|---|
| Type | Tube Less |
| Front Size |
12 Inches 30 PSI(2.1 kgf/cm2) |
| Rear Size |
12 Inches 30 PSI(2.1 kgf/cm2) |
| Breaks | |
|---|---|
| Front | Drum |
| Rear | Drum |
| Lamps | |
|---|---|
| Head | LED |
| Tail | LED 12 V 5W Bulb |
| Blinkers | LED 12 V 5W Bulb |
| Others | |
|---|---|
| Side Stand Sensor | Yes |
| Wheels | Hub Type |
| Speedometer | Digital Display |
| Ground Clearance | 215 mm |
