| Vehicle Dimensions | |
|---|---|
| Length | 3150 mm |
| Width | 1160 mm |
| Height | 1445 mm |
| Wheelbase | 1970 mm |
| Weight | 250 – 280 KGs (per battery Capacity)
|
| Payload | 344 KGs |
| Max. Speed | 30 K/hrM |
*Range (per Charge)
|
140 – 150 Km(90 Ah Battery) |
| – | – |
| – | – |
| Motor | |
|---|---|
| Type | BLDC Motor |
| Output | 1200 Watts |
| No Load Revolution | 350 RPM |
| Low Voltage Protection | 72 V |
| Battery | |
|---|---|
| Type | Lithium Ferrous Phosphate |
| Charging In | 8.5 Hrs – 9 Hrs (90 Ah) |
| Capacity | 90 Ah |
| Voltage | 72v |
| Controller | |
|---|---|
| Power Rating | 1200 Watts |
| Operating Voltage | 72 V |
| Suspension | |
|---|---|
| Front | Telescopic Fork |
| Rear | Hydraulic Shock Absorbers |
| Tyre | |
|---|---|
| Type | Tube Less |
| Front Size | 10 Inches 30 PSI(2.1 kgf/cm2) |
| Rear Size | 10 Inches 30 PSI(2.1 kgf/cm2) |
| Breaks | |
|---|---|
| Front | Drum |
| Rear | Drum |
| Lamps | |
|---|---|
| Head | LED |
| Tail | Bulb |
| Blinkers | LED |
| Others | |
|---|---|
| Side Stand Sensor | Yes |
| Wheels | DRum |
| Speedometer | Digital Display |
| Ground Clearance | 140 mm |
